Crushers, conveyors and mixing plants, designed and load-tested in Serendah, Selangor since 1987.
Catalogue · 48 machines
Inside the TM-JC600
Tap a numbered point on the machine to see what each part does and how it is specified.
Configurator
Pick the size, drive and options. The build code, output and lead time update as you choose.
The jaw crusher range
Output depends on rock hardness and closed-side setting. Figures for granite at 20 MPa feed strength.
Where it works
The same frame and jaw geometry, set up differently for hard rock, mixed demolition waste and abrasive ore.
Primary crushing at the face or behind the dump hopper, feeding a cone and screens for road base and concrete aggregate.
Hardox-lined chute and an overband magnet pull rebar out, so crushed concrete sells as recycled aggregate.
Tin tailings, iron ore and bauxite. Heavier toggle, sealed bearings and remote vibration monitoring for long shifts.
Case studies
Three Malaysian sites, measured over the first year with the site’s own weighbridge and maintenance logs.
A TM-JC800 now feeds the existing cone. The hydraulic toggle cut setting changes from half a shift to twenty minutes.
A mobile TM-JC600 crushes slab and kerb on site. What used to go to landfill now leaves as 0–40 mm recycled aggregate.
Reversible Mn18Cr2 plates and a tighter feed curtain doubled the time between plate changes on abrasive feed.
Before it ships
Each unit runs under load in our test bay before dispatch. The signed record travels with the machine and stays on file for its working life.
| Check | Requirement | Method | Result |
|---|---|---|---|
| Load run | 48 h at rated feed | Continuous run, test bay | Pass |
| Bearing temperature | ≤ 70 °C | Thermal probe, hourly | Pass |
| Vibration | ≤ 7.1 mm/s | ISO 10816 sensor | Pass |
| Weld inspection | No defects | Visual + dye penetrant | Pass |
| Paint thickness | ≥ 120 µm | DFT gauge, 10 points | Pass |
| Safety guards | All fitted | Checklist sign-off | Pass |
Order to first tonne
Typical for an in-stock TM-JC600 with electric drive. Our own crew handles every step, so there is one number to call.
An engineer visits, samples your feed and confirms the model and setting.
Frame welded and stress-relieved; shaft and bearing housings machined on our CNC line.
Run under load in the test bay. The signed test record is issued.
Our low-loader anywhere in Peninsular Malaysia; Sabah and Sarawak by sea.
Our crew sets the machine, aligns the belts and runs it on your rock.
Half a day for operators and fitters, plus a wear-parts plan for year one.
Service & spare parts
Field fitters based in Serendah, Ipoh and Johor Bahru. Wear parts for every Teras crusher since 1987 are kept on the shelf.
| Wear part | Fits | Typical life | Stock |
|---|---|---|---|
| Jaw plate set, Mn18Cr2 | TM-JC400 to JC1000 | 150,000–400,000 t | In stock · ships today |
| Toggle plate | All jaw crushers | Replace after overload | In stock · ships today |
| Spherical roller bearing 22344 | TM-JC600, JC800 | 25,000 h | In stock · ships today |
| SPC V-belt set | All jaw crushers | 6,000 h | In stock · ships today |
| Cheek plate pair | TM-JC800, JC1000 | 300,000 t | 2 sets left · 1 week |
Questions buyers ask
Take your hourly target and the largest rock your loader drops in. The feed opening should be about 1.2 × that rock size; the output range in the table above then narrows it to one model. Send us both figures and an engineer confirms within 48 hours.
Yes. Choose the diesel drive in the configurator. It adds about two weeks and 900 kg, and comes with a 1,000 L day tank and remote fuel gauge.
On granite, a set typically crushes 150,000–200,000 tonnes per side. The plates are reversible, so you flip them once before replacing. Limestone and recycled concrete give much longer life.
24 months on parts and labour for the frame, shaft and bearings, and 12 months on the motor. Wear parts are covered against manufacturing defects only.
We buy back older Teras and other makes as part payment. Rebuilt units are sold with a 12-month warranty and their own test record.
We work with Malaysian leasing companies on 3- to 5-year hire purchase. A quote can include the monthly instalment on request.
Send material, tonnage and site details. An engineer replies with a costed proposal within 48 hours.
